硅 PIN 光电二极管
S5971
高速响应 (100 MHz)
S5971 是一款高速硅 PIN 光电二极管，设计用于可见光到近红外光检测。该光电二极管以低偏压提供宽波段特性，使其适用于光通信和其他高速光度测定。
特点
- 高速响应：100 MHz（VR=10 V）
-价格低廉
-高可靠性
详细参数
| 受光面 | φ1.2 mm |
|---|---|
| 像素数 | 1 |
| 封装 | 金属 |
| 封装类别 | TO-18 |
| 散热 | 非冷却型 |
| 反向电压（最大值） | 20 V |
| 灵敏度波长范围 | 320 至 1060 nm |
| 最大灵敏度波长（典型值） | 920 nm |
| 感光灵敏度（典型值） | 0.55 A/W |
| 暗电流（最大值） | 1000 pA |
| 截止频率（典型值） | 100 MHz |
| 结电容（典型值） | 3 pF |
| 噪声等效功率（典型值） | 7.4×10-15 W/Hz1/2 |
| 测量条件 | 典型值 Ta=25°C，感光灵敏度：λ = 780 nm，暗电流：VR = 10 V，截止频率：VR = 10 V，结电容：VR = 10 V，f = 1 MHz，噪声等效功率：VR = 10 V，λ = λp，除非另有说明 |
光谱灵敏度特性
外形尺寸图（单位：mm）
