硅光电二极管
S12915-66R
适用于可见光至红外波段，通用光度计
S12915 系列在可见光至近红外范围内具有高灵敏度。
其灵敏度高于 S2387 系列，而且可用于高湿度环境。
特点
- 在可见光至红外波段具有高灵敏度
- 低暗电流
- 高线性度
详细参数
| 章程 | S12915-66R | S2387-66R（传统产品） | 单位 |
|---|---|---|---|
| 窗材 | 塑料灌封 | - | |
| 封装 | 8.9 × 10.1 | mm | |
| 受光面尺寸 | 5.8 × 5.8 | mm | |
| 有效光敏区 | 33 | mm2 | |
| 反向电压（最大值） | 30 | V | |
| 工作温度 | -20 ～ +60 | ℃ | |
| 储存温度 | -20 ～ +80 | ℃ | |
| 光谱响应范围 | 340 ～ 1100 | nm | |
| 最大灵敏度波长 | 960 | nm | |
| 感光灵敏度（典型值） | 0.64 | 0.58 | A/W |
| 短路电流（典型值） | 33 | 31 | μA |
| 暗电流（最大值） | 50 | pA | |
| ID 温度系数 | 1.12 | 次/°C | |
| 上升时间（典型值） | 9 | 10 | μs |
| 结电容（典型值） | 4000 | 4300 | pF |
| 分流电阻（典型值） | 10 | GΩ | |
| 噪声等效功率 | 2.0 × 10-15 | 2.2 × 10-15 | W/Hz1/2 |
| 测量条件 | 典型值 Ta=25°C，感光灵敏度：λ=λp，暗电流：VR=10 mV，上升时间：VR=0 V，f=10 kHz，分流电阻：VR=10 mV，噪声等效功率：VR=0 V，λ=λp，除非另有说明 | - | |
光谱灵敏度特性
暗电流与反向电压
外形尺寸图（单位：mm）
相关文档
