硅光电二极管
S1337-66BQ
详细参数
| 受光面 | 5.8 × 5.8 mm |
|---|---|
| 封装 | 陶瓷 |
| 封装类别 | -- |
| 制冷 | 非冷却型 |
| 反向电压（最大值） | 5 V |
| 光谱响应范围 | 190 至 1100 nm |
| 最大灵敏度波长（典型值） | 960 nm |
| 感光灵敏度（典型值） | 0.5 A/W |
| 暗电流（最大值） | 100 pA |
| 上升时间（典型值） | 1 μs |
| 结电容（典型值） | 380 pF |
| 噪声等效功率（典型值） | 1.3×10-14 W/Hz1/2 |
| 测量条件 | 典型值 Ta=25°C，感光灵敏度：λ = 960 nm，暗电流：VR = 10 mV，结电容：VR = 0 V，f = 10 kHz，除非另有说明 |
光谱灵敏度特性
外形尺寸图（单位：mm）
相关文档
