硅光电二极管
S9219-01
| 受光面 | 3.6 × 3.6 mm |
|---|---|
| 封装 | 金属 |
| 封装类别 | TO-5 带滤波器 |
| 制冷 | 非冷却型 |
| 反向电压（最大值） | 5 V |
| 光谱响应范围 | 380 至 780 nm |
| 最大灵敏度波长（典型值） | 550 nm |
| 感光灵敏度（典型值） | 0.22 A/W |
| 暗电流（最大值） | 50 pA |
| 上升时间（典型值） | 0.5 μs |
| 结电容（典型值） | 150 pF |
| 测量条件 | 典型值 Ta=25°C，感光灵敏度：λ=λp，暗电流：VR=10 mV，上升时间：VR = 0 V，结电容：VR = 0 V，f = 1 kHz，除非另有说明 |
光谱灵敏度特性
外形尺寸图（单位：mm）
相关文档
相关产品
