ORCA®-spark 数字 CMOS 相机
ORCA-spark 是一款使用 230 万像素 CMOS 传感器的高灵敏度数字 CMOS 相机。
它具有全局快门,可实现约 65 帧/秒的快速读出,是快速移动物体成像的理想选择。
ORCA-spark 还提供低至 6.6 个电子的读出噪声水平,即使在捕获暗物体图像时也能实现高信噪比成像。
ORCA是日本滨松光子学株式会社,及其全球子公司(欧洲联盟、日本、英国、美国)注册使用的商标。
产品编号 | C11440-36U |
---|---|
成像设备 | CMOS 图像传感器 |
有效像素数 | 1920 (H) × 1200 (V) |
细胞大小 | 5.86 μm (H) × 5.86 μm (V) |
有效面积 | 11.25 mm (H) × 7.03 mm (V) |
最大阱容 | 33,000 个电子 |
读出速度 | 64.9 帧/秒(全分辨率) 2008.9 帧/秒(2 行子阵列) |
读出噪声 | 6.6 个电子 |
曝光时间 | 26.17 μs 至 10 s(内部模式) 26.17 μs 至 10 s(外部触发模式:边缘、启动) 1 ms 至 1 s(外部触发模式:电平,同步读出) |
动态范围 | 5000:1 典型值*1 |
模拟增益 | 1× 至 15.8×(240 步长) |
子阵列 | 是 |
像素合并 | 2 × 2 *2 |
外部触发模式 | 是 |
外部触发器输入 | 边缘触发、电平触发、同步读出触发、启动触发 |
外部触发信号路由 | SMA |
触发延迟功能 | 0 μs 至 10 s,步长为 1 μs |
触发输出 | 可编程定时输出、低输出、高输出、全局曝光定时输出、触发就绪输出 |
接口 | USB 3.0*3 |
连接器 | USB 3.0 MicroB 型 |
AD 转换器 | 12 位 |
透镜接口 | C 型接口 |
电源 | AC 100 V 至交流 240 V,50 Hz/60 Hz |
用电功耗 | 约 20 VA |
操作环境温度 | 0 ℃ 到 +40 ℃ |
存储环境温度 | -10 ℃ 到 +50 ℃ |
操作环境湿度 | 强制风冷时为 30% 至 80%(无雾气现象) |
存储环境湿度 | 最高 90%(无雾气现象) |
*1 根据最大阱容和读出噪声的比率计算。
*2 相机中的数字像素合并处理。
*3 兼容 USB 3.1 Gen 1
